Power handling RMS / Max.

 P

80 / 120 Watts

Frequency response

60 Hz – 22,000 Hz

Impedance

Z

3 Ω

Sensitivity

 SPL

92 dB @ 2.83V / 1m
88 dB @ 1W / 1m

Outer diameter

ø

Tweeter: 32.0 mm / 1.26”
Midbass: 166.0 mm / 6.54”

Installation diameter

ø

Tweeter: 32.0 mm / 1.26”
Midbass: 143.0 mm / 5.63”

Installation depth

Tweeter: 9.8 mm / 0.39”
Midbass: 61.4 mm / 2.42”

Dimensions crossover

103.3 x 50.4 x 25.0 mm /
4.07 x 1.98 x 0.98”

Midbass

Impedance

Z

3 Ω

DC resistance

Re

3.0 Ω

Resonance frequency

Fs

62 Hz

Mechanical Q factor

Qms

4.50

Electrical Q factor

Qes

0.90

Total Q factor

Qts

0.75

Compliance

Cms

520 μm/N

Equivalent air volume

Vas

14.5 L

Force factor

B*l

4.1 Tm

Cone area

Sd

141 cm2

Moving mass

Mms

13.2 g

Mechanical resistance

Rms

1.10 kg/s

Voice coil diameter

 ø

25 mm

Voice coil winding height

8.9 mm

Max. linear excursion

Xmax

+/- 2.5 mm

Tweeter

Impedance

Z

4 Ω

Resonance frequency

Fs

2000 Hz

Voice coil diameter

ø

20 mm

Features

Tweeter

Ultra compact, silk dome, neodymium magnet and FlexMount20

Midbass

Injected polypropylene cone

Crossover

Tweeter: 12 dB highpass, protection and level adjustment
