Power RMS  ≤ 1% THD+N

– @ 4 Ohms

6 x 100 Watts

– @ 2 Ohms

6 x 100 Watts

– @ 1 Ohm

–

– bridged @ 4 Ohms

3 x 200 Watts

– bridged @ 2 Ohms

–

Max. output power per channel*

Up to 130 Watts RMS @ 4 / 2 Ohms

Amplifier technology

Class D

Inputs

6 x RCA / Cinch
6 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Remote In

Input sensitivity

RCA / Cinch 1 – 4 Volts
Highlevel 5 – 20 Volts

Input impedance RCA / Cinch

22 kOhms

Input impedance highlevel

9 – 33 Ohms or 20 kOhms

Outputs

6 x Speaker output
4 x RCA / Cinch
2 x Remote Out

Output voltage RCA / Cinch

6 Volts

Frequency response

20 Hz – 22,000 Hz

DSP resolution

64 Bit

DSP power

295 MHz (1.2 billion MAC operations/second)

Sampling rate

48 kHz

DSP type

Audio signal processor

Signal-to-noise ratio digital input

105 / 108 dB Speaker / Line Output (A-weighted)

Signal-to-noise ration analog input

102 / 105 dB Speaker / Line Output (A-weighted)

Distortion (THD)

< 0.03 / 0.005 % Speaker / Line Output

Damping factor

100

Operating voltage

10.5 – 16 Volts (max. 5 sec.down to 6 Volts)

Idle current

1950 mA

Max. remote output current

500 mA

Operating temperature range

-40° C to +70° C

Fuse

2 x 35 A Maxi-fuse (APX)

Power rating

DC 12 V ⎓ 80 A max.

Additional features

ADEP.3 circuit, Auto Remote switch, 32 Bit CoProcessor, Control Input

Dimensions (H x W x D)

50 x 320 x 154 mm /
2.00 x 12.60 x 6.06”
