Output power RMS  ≤ 1% THD+N

– @ 4 Ohms

1 x 240 Watts

– @ 2 Ohms

1 x 410 Watts

– @ 1 Ohm

1 x 600 Watts

– bridged @ 4 Ohms

–

– bridged @ 2 Ohms

–

Max. output power per channel*

Up to 720 Watts RMS @ 1 Ohm

Amplifier technology

Class D

Inputs

2 x RCA / Cinch
2 x Highlevel speaker input
1 x Remote In
1 x Remote control input

Input sensitivity

RCA / Cinch 0.5 – 6 Volts
Highlevel 1.1 – 13 Volts

Input impedance RCA / Cinch

20 kOhms

Input impedance highlevel

13 Ohms

Outputs

1 x Speaker output

Output voltage RCA / Cinch

–

Signal converter for digital input

–

Frequency response

10 Hz – 250 Hz

Bass boost

0 – 12 dB / 25 – 75 Hz

Highpass

–

Lowpass

50 Hz – 250 Hz adjustable

Bandpass

10 Hz – 250 Hz adjustable

Subsonic

10 Hz – 50 Hz adjustable

Phase

0 – 180° adjustable

Slope high- / lowpass

–

Slope subsonic / lowpass

12 / 24 dB/Oct.

Signal-to-noise ratio digital input

–

Signal-to-noise ratio analog input

95 dB (A-weighted)

Distortion (THD)

0.20 %

Damping factor

100

Operating voltage

10.5 – 16 Volts (max. 5 sec. down to 6 Volts)

Idle current

650 mA

Operating temperature range

-40° C to +70° C

Fuse

2 x 35 A Maxi-fuse (APX)

Additional features

Active, adjustable crossover, bass boost, phase shift, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control

Dimensions (H x W x D)

50 x 230 x 154 mm /
2.00 x 9.06 x 6.06”
