Output power RMS  ≤ 1% THD+N

– @ 4 Ohms

6 x 100 Watts

– @ 2 Ohms

6 x 100 Watts

– @ 1 Ohm

–

– bridged @ 4 Ohms

3 x 200 Watts

– bridged @ 2 Ohms

–

Max. output power per channel*

Up to 130 Watts RMS @ 4 / 2 Ohms

Amplifier technology

Class D

Inputs

6 x RCA / Cinch
1 x Remote In

Input sensitivity

RCA / Cinch 0.5 – 6 Volts

Input impedance RCA / Cinch

20 kOhms

Input impedance highlevel

–

Outputs

6 x Speaker output

Output voltage RCA / Cinch

–

Signal converter for digital input

–

Frequency response

10 Hz – 30,000 Hz

Bass boost

–

Highpass

15 Hz – 4,000 Hz adjustable

Lowpass

40 Hz – 4,000 Hz adjustable

Bandpass

15 Hz – 4,000 Hz adjustable

Subsonic / HPF

15 Hz – 4,000 Hz adjustable

Phase

–

Slope high- / lowpass

12 dB/Oct.

Slope subsonic / lowpass

–

Signal-to-noise ratio digital input

–

Signal-to-noise ratio analog input

98 dB (A-weighted)

Distortion (THD)

0.05 %

Damping factor

100

Operating voltage

10.5 – 16 Volts (max. 5 sec. down to 6 Volts)

Idle current

1,550 mA

Operating temperature range

-40° C to +70° C

Fuse

2 x 35 A Maxi-fuse (APX)

Power rating

DC 12 V ⎓ 80 A max.

Additional features

Active, adjustable crossover, subsonic input mode switch channel E / F, subsonic, Start-Stop capability

Dimensions (H x W x D)

50 x 320 x 154 mm /
2.00 x 12.60 x 6.06”
